PAMAS S40 GO

PAMAS S40 GO

Compact mobile particle counting device for on-site analysis.

Methods:SAEAS 4059NAS1638GJB420AISO4406GOST17216
Login or Register to buy
Applications: Military | Marine | Field Service Labs | Mining
  • Portable design for use in diverse locations.
  • Accurate detection of a wide range of particle sizes.
  • Real-time data display and recording.
  • Simple operation.
  • Compliant with industry standards analysis.

Key Features

ISO logo icon, representing compliance with International Organization for Standardization test methods
ISO
CompliantFully compliant with ISO 4406:1999 at 4 µm(c), 6 µm(c) and 14 µm(c) based on ISO 11171, and with ISO 4406:1987 at 2 µm, 5 µm and 15 µm based on ISO 4402
Portable analyzer with carrying handle icon
Fully
PortableFully Portable: Real portability with laboratory system accuracy, and a configurable profile system that adapts the instrument to the user’s needs
Grey ribbed steel carrying case with a handle, representing a rugged water-tight transport case
Rugged
CaseRugged Case: A water-tight steel case protects the instrument in harsh environments and during transportation
Multilingual analyzer operation icon
Multilingual AccessibilityMultilingual Accessibility: Display and print-out formats in English, Spanish, Dutch, Finnish, Portuguese, Russian, Chinese and French. The system can be programmed to any other language as an option
Multi-position autosampler icon
Optional
AutosamplerOptional Autosampler: A range of flexible options is available, including the Liquids Auto Sampler
Printer producing a printed report icon, representing the optional on-board result printer
Printer
OptionPrinter Option: An optional printer allows results to be printed directly from the instrument for immediate hard-copy reporting
Hand touching a control surface beside a green badge showing the number 10, representing user programmable stored methods
Programmable MethodsProgrammable Methods: Operators can create and save their own test methods. Any method saved to memory can be recalled and run directly from the instrument
Icon of a hand touching a color tablet touchscreen, representing immediate on-screen display of analyzer results
Touch
ScreenTouch Screen: Easy view of various information with straightforward, user-friendly operation. Display colours can be changed
Display panel showing a thermometer and a temperature reading in degrees, representing an on-board LCD temperature display
Temperature DisplayTemperature Display: An LCD temperature display shows sample temperature directly on the instrument to support measurement accuracy
Clock face with a blue duration arc icon, representing a configurable integrated measurement timer
Integrated
TimerIntegrated Timer: Measurement duration can be set directly on the instrument, letting operators match sampling time to the requirements of the application
Icon of a fuel sample droplet centered on a crosshair target, representing high measurement precision
High
PrecisionHigh Precision: The volumetric cell design of the sensors guarantees the highest accuracy, resolution and statistical information, and a pressurised sensor avoids the formation of gas bubbles

The rugged and resistant PAMAS S40 GO portable particle counter is built to meet the demands of the harshest environments and can be used for field analyses and for laboratory measurements. The electronic particle counter includes an integrated battery for mains free operation on site. It is small and light enough to fit into an aircraft overhead locker.

The rugged case of the PAMAS GO electronic particle counter is watertight and protects the instrument in harsh environments and during transportation.

The incorporated tried and tested PAMAS high-resolution sensor technology is trusted throughout the industry for its reliability and accuracy user-friendly download software for transfer of stored measurement data to a PC as a basic feature. Data files on the portable electronic particle counter are compatible with most spreadsheet software. Standard languages are English, German, Finnish, Dutch, French, Spanish, Portuguese, Chinese and Russian. The system can be programmed to any other language (optional). The optional carrying bag for the rugged case PAMAS GO portable particle counter is equipped with a shoulder strap and three handy side pockets.

Segments:AdditivesBiofuelsCrude / ExplorationEnvironmentalGas (LPG, CNG, LNG)Jet Fuel / AvGasLubes / O.C.M. / MiningPharma / ChemicalsRefineryWater Testing (OIW)

Specs

Applicable Test Methods ISO 4406, SAE AS 4059 E, NAS 1638, GJB 420A, GOST 17216
Technical data Sampling system • Wear resistant ceramic piston pump with controlled constant flow
• Viscosity range up to 200 cSt (pressurised sampling up to 350 cSt; lube oil system up to 1,000 cSt)
Pressure range • Low pressure: from pressureless up to 6 bar (85 psi)
• High pressure: 3-420 bar (6000 psi)
PAMAS Volumetric Sensor: HCB-LD-50/50 Calibration ranges:
• 4-70 µm(c) according to ISO 11171 (standard calibration)
• 2-100 µm according to ISO 4402 (optional calibration)
Max. particle concentration:
• 24.000 P/ml at a fl ow rate of 25 ml/min and a coincidence rate of 7.8%
Counter • 8-channel particle counter • 32-bit high performance CPU with sophisticated programmable digital domain signal conditioning and 4096 internal channels
• Data printout: 32 column thermo printer
• Data transfer: 8 bit ASCII code through USB port
• Power supply: 90-240 V AC / 50-60 Hz or 12-30 V DC or via integrated battery for up to three hours operation
• Weight and Size: Approx. 8 kg 340 mm x 220 mm x 420 mm
