ERASPEC OIL
Advanced spectroscopic analyzer for on-site oil analysis.
- High-precision FTIR spectroscopy for accurate analysis
- Comprehensive oil analysis
- Fast and reliable results in less than a minute
- Portable and rugged design for field use
- Complies with ASTM, JOAP and many other standards
Key Features
ASTM
CompliantFully compliant to ASTM D86, D323, D613, D1655, D2699, D2700, D4814, D5191, D5845, D6277, and D6378, providing both standard method and refined methodology
Multilingual AccessibilityMultilingual Accessibility: Operation and output capabilities in the following languages: English, Spanish, Portuguese, Russian, Chinese (coming soon), French (coming soon)
Straightforward OperationStraightforward Operation: An intuitive menu structure ensures seamless user navigation, with no prior sample preparation and fully automated measurement
Touch
ScreenTouch Screen: All eralytics analyzer results are displayed immediately after the test on their large and user-friendly color touch screen
Small
FootprintSmall Footprint: The compact footprint of the eralytics instruments makes them the first choice for use in the lab and on-site
Fully
PortableFully Portable: An accessible design that is lightweight and has an integrated carrying handle allows for suitable and smooth mobility
Enhanced Output EfficiencyEnhanced Output Efficiency: A direct out-of-the-box connection to LIMS is established with a standard ethernet cable — no extra software or PC required
Videos
ERASPEC OIL / In-service lubricant monitoring
Oil change, revealed
before downtime.
Introducing the ERASPEC OIL: advanced FTIR analysis for in-service lubricant monitoring
The ERASPEC OIL is a high-precision FTIR spectrometer specifically engineered for comprehensive analysis of oils. This powerful device is essential for monitoring oil conditions in industrial applications, ensuring equipment reliability, and optimizing maintenance schedules. The ERASPEC OIL utilizes mid-infrared spectrometry to measure key oil degradation parameters, including oxidation, nitration, and soot levels, with unmatched accuracy. Designed to adhere to global standards such as ASTM, JOAP, and DIN, it guarantees reliable and consistent results crucial for oil condition monitoring.
Fast + Fully automated
One minute.
A full oil picture.
This device is incredibly user-friendly and fully automated, with a quick start-up time and no need for sample preparation.
Within about a minute, the device can analyze a sample as small as 10 mL, providing vital information directly on its intuitive touchscreen interface. The rugged, portable design, 29 × 35 × 34 cm (11.4 × 13.8 × 13.4 in) and light weight of 9.7 kg (21.4 lb), ensures that the ERASPEC OIL is perfect for both lab-based analysis and field applications, making it an ideal solution for on-site oil monitoring in demanding industrial environments.
10 mL is all it takes.
Vital information is delivered directly on the intuitive touchscreen interface, in 60 to 120 seconds depending on the viscosity of the sample.
Designed for both settings
- Quick start-up time
- No sample preparation
- Lab-based analysis
- Field applications
Comprehensive oil analysis
Track degradation.
Act before downtime.
The ERASPEC OIL is unique due to its comprehensive oil analysis. There are certain parameters like TAN, TBN, nitration, oxidation, water content, and soot that are measured in this equipment and crucial for general oil analysis.
It supports trending analysis and spectral subtraction for advanced oil condition monitoring, making it an invaluable tool for predicting equipment maintenance needs and avoiding costly downtime. The data management system of this unit is capable of seamless integration into existing workflows, with options for data storage in the equipment, USB transfer, RS232 interfaces, direct LIMS connectivity via LAN, and direct report printing.
Applications of the ERASPEC OIL include
Comprehensive oil analysis supports condition monitoring from the lab to the field.
Where ERASPEC OIL works
- Monitoring the condition of oils
- Predictive maintenance and reliability engineering
- Highly accurate on-site oil analysis for quick decision-making in field operations
- Research and development in oil performance and formulation
Key measuring parameters
Three signals.
A clearer oil condition.
- 01
TAN and TBN
Measuring total acid and base numbers of oil, crucial for assessing its properties.
- 02
Nitration and Oxidation
Detecting nitrogen compounds that indicate the degradation of oil, and obtaining the level of oil oxidation, which is important to assess oil usage.
- 03
Water content and Soot
Detecting water content and measuring soot contamination levels to prevent engine wear.
Specs
| Standard Test Methods | ASTM E2412, ASTM D2668, ASTM D7214, ASTM D7412, ASTM D7414, ASTM D7415, ASTM D7418, ASTM D7624, ASTM D7844, ASTM D8340, DIN 51452, DIN 51453, IEC 60590, IEC 60666, and JOAP | |
| Correlation to | ASTM D611, ASTM D664, ASTM D2896, ASTM D4739, and ASTM D6304 | |
| Spectrometer Type | Patented mid-FTIR spectrometer Laser and temperature controlled design |
|
| Measurement Cell | 100 µm and 500 µm path length Optimized triple position cell design enabling automated reference measurement without solvent |
|
| Calibration | Factory calibrated with a matrix of international lubricants eralytics´calibrations for soot, water, glycol |
|
| Spectral Libraries | Easy expandable libraries to adjust measurements to target applications and user-defined parameters | |
| Measurement Principles | Direct trending: calculation of results without the need to record a fresh opil spectrum Spectral subtraction: fresh oil used as reference for highest performance and lowest LODs |
|
| Measuring Time | 60 – 120 seconds depending on the viscosity of the sample; Warm-up time: 30 seconds after booting the instrument |
|
| Sample Introduction | Directly from the sample container by an integrated pump | |
| Sample Viscosity | 0 – 2 000 cSt at 20 °C | |
| Sample Volume | 10 mL | |
| Cleaning | Automatic rinsing with next sample or solvent Integrated filter to prevent blocking of measurement cell |
|
| Display | Industry proven 8.4″ color touchscreen | |
| Languages | English, German, French, Spanish, Russian, Chinese Additional langages available upon request |
|
| Interfaces | Built-in PC with Ethernet, USB and RS232 interfaces Direct LIMS connectivity via LAN, output to printer or PC and export as CSV or PDF Optional input by external keyboard, mouse, and barcode scanner |
|
| Remote Control | Remote service capability via Ethernet interface | |
| PC Software | ERASOFT RCS – remote control Windows® software for multi-instrument remote control, convenient data transfer, viewing spectra and result analysis
ERASOFT OCM software – supports operators in the management, operation and predictive maintenance of technical equipment with a focus on oil condition monitoring |
|
| Result Database | 50 000+ detailed test reports and spectra storable in internal memory | |
| Alarm Tracking | All alarm messages are stored in the database together with the results | |
| Auto Sampler | Optional 10-position auto-sampler – directly attached | |
| Operating Conditions | Temperature range 5 °C to 45 °C Humidity up to 90% RH, non-condensing |
|
| Power Requirements | Auto switching 85-264 V AC, 47-63 Hz, max. 150 W (multi-voltage power supply) Field application: 12 V DC (vehicle battery) adapter available |
|
| Dimensions / Weight | (W x D x H) = 29.1 x 32.9 x 34.8 cm (11.5 x 12.9 x 13.7 in) / 10.6 kg (23.4 lb) |
