ERAVAP LPG

Advanced vapor pressure tester for LPG (Liquefied Petroleum Gas).

Key Features:

  • Accurate vapor pressure measurement for LPG
  • Rapid analysis, high repeatability with high precision
  • Portable and robust design
  • Easy operation with intuitive interface
  • Meets different standards
Methods:
ASTM, D323, D5191, D6378, D2533, D910, D1267, D4953, D5188, D5190, D6377, D6897, EN, 13016-3, 13016-1-2, 228, IP, 394, 409, 481, JIS, K2258-2

Login or Register to buy or

Introducing the ERAVAP- LPG Advanced vapor pressure testing for liquid petroleum gasses (LPGs)

The ERAVAP LPG is a highly precise, compact, user-friendly Reid Vapor Pressure (RVP) and Dry Vapor Pressure Equivalent (DVPE) tester augmented by a doubled pressure operating range up to 2000 kPa. The ERAVAP LPG's precision ensures reliable volatility specification in a wide variety of research and mobile applications.

This device is designed for the everyday user and is fully automated, with minimal operator interactivity.
A small footprint, navigable interface, rugged aluminum casing, and simple operations make the ERAVAP a desirable unit for both laboratory and on-the-go vapor pressure testing. Quick connect inlets paired with a pressurized cylinder ensure LPG's maintain a pressurized environment to retain the sample from escaping due to its high volatility.

This device is fully compliant with ASTM D6897 making it the ideal unit for R&D, QC, and many more applications using a single analyzer.

Applications of the ERAVAP LPG Include:
Analyze gas pressure potential in systems
Ensure safe high pressure system design
Maintaining regulatory compliance

Key Measuring Parameters:
Volatility: DVPE/RVPE measurement describing volatility profile
Pressure Distribution: Gas (Pgas), absolute (Pabs), and total (Ptot) pressure measurements for each sample
Vaporization Tendency: V/L ratio gives insight into the tendency of fuel to vaporize in an engine

The ERAVAP is backed by a comprehensive 1-year warranty, with an option to extend coverage for an additional year upon compliance with the manufacturer’s terms.
For more information or to request a quote, please click here.
For other related devices see the ERAVAP ONLINE or ERAFLASH.

Features

features__astm compliantERAVAP is fully compliant with ASTM D1267, ASTM D323, ASTM D4814, ASTM D4953, ASTM D5188, ASTM D5190, ASTM D5191, ASTM D6377, ASTM D6378, ASTM D6897, ASTM D910, providing both standard method and refined methodology.
features__simple operatonAll eralytics analyzers use an intuitive menu structure that is easy to navigate. Samples need no prior preparation and measurements are done fully automated.
A direct out-of-the-box connection to LIMS (Laboratory Information Management System) is established with a standard Ethernet cable.No extra software or PC are necessary.
features__footprintThe small footprint of the eralytics instruments makes them the first choice for use in the lab and on-site.
features__touch screenAll Eralytics analyzer results are displayed immediately after the test on their large and user-friendly color touch screen.
features__high precisionThe outstanding precision of the ERAVAP is the result of combining the innovative measurement cell design with a choice of cutting-edge instrument parts. Among those count a self-lubricating piston drive, a built-in shaker motor and state-of-the-art solenoid valves that prevent cross contamination between samples. The ERAVAP instrument clearly outperforms the standard methods in terms of repeatability and reproducibility. (r = 0.3 kPa, R = 0.7 kPa).
features__portableThe Eralytics units are all lightweight and built with an integrated carrying handle, they are versatile and ideally suited for mobile applications as well.

Accessories

The following accessories are recommended for purchase in sequential order (see eStore):

1st Year: No spare parts are required
2nd Year: Sampling tube with Luer connector
Sampling tube 0,5m with Luer connector
Teflon o-ring for EV01-A002a Mesh inlet filter 80µ
Outlet tube
Kalrez O-ring for pressure sensor (Kalrez 12.42×1.78)
O-ring small for measuring cell cover (Viton 6×1.5)
Remaining Parts:

Specs

Available Test Methods ASTM D5188, D5191, D6377, D6378, D6897, EN13016-1, EN13016-2, EN13016-3 ,IP394, IP409, IP481, JIS K2258-2, SHT 0769, SHT 0794, SNT 2932, GOST 52340 freely programmable methods EPA / CARB / US Military & NATO reference methods, TVP measurement VP-V/L Speed TestTM – Combined T(V/L) and vapor pressure measurement
Correlation to… ASTM D323, D1267, D2533, D4953, D5190, D5482
Fuel Specifications ASTM D910, D1655, D4814, D6227, EN 228
Temperature Range 0 °C to 120 °C (32 °F to 248 °F) with Peltier technology. No external cooling is required. -20 °C to 120 °C (-4 °F to 248 °F) with additional low temperature upgrade (EV01-COOL). External cooling is required. Extrapolated range: -100 to 300 °C (-148 °F to 572 °F)
Temperature Stability 0.01 °C (0.02 °F)
Pressure Range 0 kPa to 2 000kPa (0psi to 290 psi)
Pressure Units (selectable) hPa, kPa, psi, mmHg, Torr, at, atm
Pressure Resolution 0.01 kPa (0.0014 psi)
Vapor / Liquid Ratio Variable from 0.02/1 to 100/1 Single-, multi-point and curve measurements
Precision Repeatability: r ≤ 0.15 kPa (0.022 psi) / Cyclopentane @ 37.8°C Reproducibility: R ≤ 0.50 kPa (0.073 psi)
Available Extension Modules EV01-COOL: Low temperature module (-20°C – 120°C / -4°F – 248°F)

EV01-VISC: High viscosity module (Heated inlet and outlet up to 70°C / 158°F)

EV01-LOW: Low vapor pressure module (r = 0.1 kPa; pressure resolution = 0.01 kPa)

Sample Introduction Automated via built-in piston Automated sample filtration through a reuseable 80 µm mesh filter No external vacuum pump is required
Sample Volume 1 mL (2.2 mL per rinsing cycle)
Measurement Time 5 minutes for a standard measurement
Cleaning By next sample or solvent
Measuring Chamber Nickel-plated aluminum chamber
Display Industry proven 8” color touch screen
Languages English, German, French, Spanish, Russian, Chinese
Additional langages available upon request
Interfaces Built-in PC with Ethernet, USB and RS232 interfaces
Direct LIMS connectivity via LAN, output to printer or PC as CSV or PDF
Optional input by external keyboard, mouse and barcode reader
Remote Control Remote service capability via Ethernet interface
PC Software ERASOFT RCS – remote control Windows® software for multi-instrument remote control, convenient data transfer, viewing spectra and result analysis
Result Database Over 100,000 detailed test reports stored in internal memory
DVPE, RVPE, PABS, PGAS, PTOT, ASVP & AVP
Results can be marked for hazy appearance
Graphical view of curve measurements
Alarm Tracking All alarm messages are stored in the database together with the result
Automated Calibration Routine 10-point probe offset correction table, calibration history tracking, substance calibration, self-diagnostics
Auto Sampler Optional 10-position auto sampler – directly attached
Operating Conditions Temperature range 0°C to 50°C, Humidity up to 90% RH, non condensing
Power Requirements Auto-switching 85-264 V AC, 47-63 Hz, max. 150 W (multi-voltage power supply)
Field application: 12 V DC (vehicle battery) adapter available
Model Number EV20
Dimensions / Weight 29 x 35 x 34 cm (11.4 x 13.8 x 13.4 in) / 9.7 kg (21.4 lb)

Downloads

Download our brochure for more details

Videos

Configuration

ASTM D6897

AYA-83-22024 EV01-D6897 Software module for the measurement of the vapor pressure of LPG
AYA-82-22237 Mesh inlet filter 80µ (5 pcs, 1 pc inside Sample inlet on an instrument)
AYA-82-22084 Outlet tube
AYA-82-22085 Waste container
AYA-82-22086 Power cable
AYA-82-22414 Quick-connector inlet nut for ERAVAP (EV10) and ERAVAP LPG (EV20)
AYA-82-22543 High-pressure filling tube (0,7m) for EV10-REG and EV20-REG
AYA-83-22193 ERAVAP MPC module for sampling & measuring pressurized crude oil
for ERAVAP
or
AYA-82-22439 ERAVAP FPC module for sampling & measuring pressurized crude oil and LPG
for ERAVAP
