StoneDDI – Stone Digital Detection Imaging
Advanced device for precise calibration and verification of diffuser stones.
Key Features:
- Accurate measurement of pore diameter and permeability under controlled air flow conditions.
- Accommodating cylindrical and spherical designs.
- High-resolution vision system for precise detection of even the smallest bubbles.
- Suitable for both ceramic and metal diffusers.
- Fully compliant with ASTM standards.
ASTM, D892, D6082, BS 2000, Part 156, FTM, 791-3211, IP, 146, ISO, 6247
Introducing the StoneDDI: Diffuser stone calibration and verification system
The Stone Digital Detection Imaging (StoneDDI) device verifies the status of new and in-use diffuser stones. The StoneDDI can calibrate both metal and ceramic cylindrical and spherical diffusers ensuring the stone is within bounds for related testing.
With tightly controlled conditions of airflow, the StoneDDI calculates and determines the pore diameter and permeability.
The StoneDDI operates in a two-test position design to determine the characteristics of the diffuser stone. With a built-in vision system, even the smallest of bubbles are captured for reliable determination of the stone parameters.
This device is fully compliant with ASTM D892, D6082, and E128-99 making it the ideal unit for R&D, QC, and many more applications.
Applications of the StoneDDI Include:
Ceramic spherical diffuser calibration
Metal cylindrical diffuser verification
Key Measuring Parameters:
Pore Diameter: Size in μm
Permeability: Flow in mL/min
The StoneDDI is backed by a comprehensive 1-year warranty, with an option to extend coverage for an additional year upon compliance with the manufacturer’s terms.
For more information or to request a quote, please click here.
For other related devices see the FoamDDI.
Features
ASTM
CompliantASTM Compliant: Fully compliant to both ASTM D892 and D6082
Straighforward OperationStraightforward Operation: 1-2-3 wizard driven software ensures seamless user operation
Multilingual AccessibilityMultilingual Accessibility: Operation and output capabilities in the following languages: English, Spanish, Portuguese, Russian, Chinese (coming soon), French (coming soon)
Reliable AutomationReliable Automation: Completely automated testing procedures from initialization through data analysis
Maximized ThermoregulationMaximized Thermoregulation: 200W IR heating bulb and 70W Peltier cooling system augments temperature management
Dependable ParametersDependable Parameters: Built in mass flow totalizer and option to use cylindrical or
spherical diffusers ensures reliable air flow
Dual Camera ConfigurationDual Camera Configuration: 800 mL foam detection range with vibration proof optics
Optional ModularityOptional Modularity: Optional modular configuration for up to four asynchronous test
positions per logic box
Enhanced Output EfficiencyEnhanced Output Efficiency: Direct ethernet and LIMS connectivity and in unit result
transfer to reports and email
Unbiased
DigitizationUniquely operational VISION algorithm with high confidence edge contrast and straightnessl
Manual and Algorithmic CooperationManual result correction available alongside the predictive analytics
Accessories
The following accessories are recommended for purchase in sequential order (see eStore):
| 1st Year: | VISAYA FOAM-DDI 1000 mL Test Cylinder Cylindrical Gas Diffuser With Certified Spherical Gas Diffuser With Certified PTFE Stopper Complete With Compression Fittings SS Air Tube (exit air) – D892 4 Position Test Cylinder Rack PTFE Sealing Washer – D892 Replacement Air Inlet Tube with Integrated Temperature Sensor – Calibrated |
| 2nd Year: | FOAM-DDI D892 Test Assembly Filter, Regulator and Dryer System for FOAM-DDI Air Supply Pump for FOAM-DDI |
| Remaining Parts: |
Specs
| APPLICABLE TEST METHODS | ASTM D892, ASTM D6082 | |
| OPERATIONAL MODE | Pore Diameter, Permeability, or Both | |
| DIFFUSER TYPES | Non-metallic Spherical, metallic Cylindrical | |
| DISPLAY UNITS | Flow mL/min , Pressure kPa | |
| DETECTION METHOD | Patent Pending CCD Digital Detection and Mass Flow Meter over Electronic Pressure Control | |
| PRECISION | +/- 0.06L Flow, +/- 0.08 kPa | |
| OPTICAL DESIGN | Patented Optical Arrangement | |
| LIGHT SOURCE | LED Red (600nm) | |
| MEASURING TIME | Operation mode dependent | |
| CALIBRATION | Flow, Pressure, and Camera | |
| DISPLAY | 10.1” Projective Capacitance Touch (Multi Touch) | |
| OPERATING SYSTEM | Modern Embedded Windows 10 | |
| INTERFACE | Ethernet x2, USB 3.0 x1, USB 2.0 x2, HDMI, VGA Serial, USB Printer, USB Mouse and Keyboard | |
| MEMORY / STORAGE | 64 GB SSD Storage | |
| TEMPERATURE RANGE | 15° to 35° C | |
| HUMIDITY | Up to 85% Non-Condensing | |
| POWER REQUIREMENTS | StoneDDI: 110/120VAC, 50/60Hz 3.2A or 220/230 VAC 50/60 Hz 1.6A, IPC Logic Control Box: Auto-switching 90 ~ 264VAC, 47 ~ 63Hz, 280 Watt Power Supply | |
| MATERIALS REQUIREMENTS | 40 psi Instrumental Grade air | |
| SPACE REQUIREMENTS | 80 mm (3”) on Sides and Back. Sides 1”, Back 6” | |
| DIMENSIONS (W X D X H) MM (INCHES) | StoneDDI: 508 x 228 x 635 (20 x 9 x 25”), IPC Logic Control Box: 304 x 254 x 152 (12 x 10 x 6”) | |
| GROSS DIMENSIONS & WEIGHT | StoneDDI: Weight 10 Kg. (22 lbs.), 400 x 350 x 530 mm, 15 Kg. (15 x 14 x 21” 35lbs.), IPC Logic Control Box: Weight 3 Kg. (7lbs.) 355 x 355 x 254 mm, 4Kg. (14 x 14 x 10” 10 lbs.) |
Video
Downloads
Download our brochure for more details
Configuration
ASTM D892
| AYA-10-88605 | IPC Logix Box – Controller with Software for FoamDDI. Support for upto 4 FoamDDI Analyzers, 110/240 |
| AYA-15-00050 | Air Supply Pump for FoamDDI, 110VAC, 60Hz. |
| AYA-52-50230 | Cylindrical Gas Diffuser. Certified Mott metal cylindrical gas diffuser for use with manual systems and VISAYA FoamDDI |
| AYA-13-89000 | FoamDDI – Air Line Connection Kit. FoamDDI Connection Kit. Consisting of Wye Adapter, 6 feet of tubing, (2) 1/4″ to 1/4″ OD Adapter, tee adapter, 4 position manifold and (2) plugs for unused ports. |
Tags
eStore
You May Also Like
-
3/16" Teflon Front Ferrule
-
4 Position Test Cylinder Rack
-
Air inlet tube
-
Certified Norton spherical gas diffuser
-
Cylindrical Mott Gas Diffuse Stone
-
Filter, Regulator and Dryer System for FoamDDI
-
FoamDDI – Stopper Assembly
-
Inline Oil Filter
-
Glass Test Cylinder
-
