Penetrometer

Pinpoint accuracy, for when precision is critical
Methods:
ASTM D5, ASTM D217, ASTM D937, ASTM D1321, ASTM D1403, ASTM D2884, DIN 51 579, DIN 51 580, EN 1426, IP 49, IP 50, IP 179, IP 310, IP 376, ISO 2137,
























































								ASTM D5, ASTM D217, ASTM D937, ASTM D1321, ASTM D1403, ASTM D2884,





								DIN 51 579, DIN 51 580,

								EN 1426,





								IP 49, IP 50, IP 179, IP 310, IP 376,

								ISO 2137,









Standard compliance, superior results

The versatile capabilities of Ayalytical Instruments’ precision cone penetrometer ensures full compliance with ASTM D5, ASTM D2178, ASTM D937, ASTM D1321, ASTM 1403, ASTM D2884, DIN 51 579, DIN 51 580, EN 1426, IP 49, IP 50, IP 179, IP 310, IP 376, and ISO 2137 testing regulations, for determining the penetration of waxes, lubricants, asphalts, and other semi-solid and solid bituminous materials.

This sturdy, easy-to- operate penetrometer for sale functions by dropping a cone into the sample bituminous material for a user-specified time at constant temperature, then measuring the depth of penetration of the cone to .10 mm accuracy.

The ever-reliable precision penetrometer comes equipped with aluminum anodized base with inset spirit level and adjustable feet to ensure precise positioning during testing; a solid, stainless steel column for supporting the test dial, which is calibrated with 360 divisions adjustable in increments of .10 mm for penetration up to 720 mm; Micrometric regulation for literal pinpoint precision in depth measurement;, and both a magnifying glass and check light for enhanced visibility.

The penetrometer for sale is available in manual precision (7 kg) and semi-automatic precision (9 kg) models. This compact precision penetrometer brandishes a release button with manual or low-voltage timed automatic halting function, respectively, and is perfect for either field or laboratory testing.

features__astm compliant

Models    Positions
Model 650   MANUAL PRECISION PENETROMETER
Model 650/SEM   SEMI-AUTOMATIC PRECISION PENETROMETER

CONE PENETRATION ½ ASTM D1403 IP 310 22.5 g., stainless steel body and tip.
CONE PENETRATION ¼ ASTM D1403 IP 310 1.20 g., PMMA body, stainless steel tip.
CONE PROPELLANTS ASTM D2884 15 g., Ø65 mm., magnesium
CONE 15 g., Ø65 mm., PMMA
MICRO-CONE ASTM 5 g., aluminum
MICRO-CONE ASTM 10 g., stainless steel
PERFORATED DISK 102.5 g., Ø70 mm., aluminum
PERFORATED DISK 19.5 g., Ø35 mm., aluminum
PERFORATED DISK 10 g., Ø39 mm., aluminum
BALL PENETRATION ASTM D3407 D3408 D5329 Made of stainless steel
PLUNGER 47.5 g., stainless steel
PLUNGER 97.5 g., stainless steel
PLUNGER ½ 15 g., aluminum (per 10-0656)
PLUNGER ¼ 8.18 g., magnesium (per 10-0657)
PLUNGER 10 g., aluminum
LOAD WEIGHT, 50 g
LOAD WEIGHT, 100 g
TRANSFER DISH Ø160×90 mm., metal, with internal serpentine heat exchanger and hose sockets, spacer plate with holes
TRANSFER DISH Ø185×90 mm., glass, with hose sockets, spacer plate with holes
SAMPLE JAR Ø33×8 mm, pack of 5 pcs For bitumen, penetration up to 40, steel
SAMPLE JAR Ø50×16 mm, pack of 5 pcs For bitumen, penetration up to 40, steel
SAMPLE JAR Ø55×35 mm, pack of 5 pcs For bitumen, penetration up to 200, steel
SAMPLE JAR Ø55×45 mm, pack of 5 pcs For bitumen, penetration from 200 to 350, steel
SAMPLE JAR Ø75×70 mm, pack of 5 pcs For bitumen, penetration from 200 to 350, steel
SAMPLE JAR Ø70×45 mm, pack of 5 pcs For bitumen, penetration from 200 to 350, steel
SAMPLE JAR Ø55×70 mm, pack of 5 pcs For bitumen, penetration from 350 to 500, steel
SAMPLE JAR Ø70×60 mm, pack of 5 pcs For bitumen, penetration from 350 to 500, steel
SAMPLE JAR Ø100×65 mm, pack of 3 pcs Steel, with cover
SAMPLE JAR Ø76.5×63.5 mm, pack of 3 pcs Steel
SAMPLE JAR Ø76×64 mm, pack of 3 pcs 2-sections
WAX TEST CYLINTER Ø25×32 mm, pack of 2 pcs
BASE PLATE 63.5×38 mm, pack of 2 pcs Brass
SAMPLE JAR Ø55×35 mm, pack of 100 pcs Aluminum
REDUCTION RING “20” EN 1426 Ring insert for reduce sample volume, for use on sample jar, ext. Ø53 int. Ø36 20 mm high, anodized aluminum
REDUCTION RING “30” EN 1426 Ring insert for reduce sample volume, for use on sample jar, ext. Ø53 int. Ø36 30 mm high, anodized aluminum
Model PEN CIRCULATING BATHWATER BATH for maitaining samples at constant temperature. Working temperature up to 80°C with decimal resolution. Digital thermoregulator with probe PT100, stainless steel heater, coiling coil, motor pump allowing the liquid circulation with sockets to connect at transfer dish, stainless steel plate for tempering directly in the bath the sample jar.
Technical specifications:
– Temperature: ambient to 80°C (176°F)
– Stability: ±0.1° C
– Power supply: 220V ±10% 50/60 Hz
– Power: 1200W.
– Dimensions: 30x35x27 cm
– Weight: 7 Kg
– Bath capacity: 5 about liters
DIGITAL STOPWATCH 7 digit LCD, max.10 hours, 1/100 sec, digit h=8 mm
THERMOMETER ASTM 17C
THERMOMETER ASTM 63C
THERMOMETER ASTM 64C[/row_cons]

Test Method Compliance   ASTM D5 ASTM D217 ASTM D937 ASTM D1321 ASTM D1403 ASTM D2884 DIN 51579 DIN 51580 EN 1426 IP 49 IP 50 IP 179 IP 310 IP 376 ISO 2137
    MANUAL PRECISION PENETROMETER
Power supply   230V ±10% 50Hz
Power   100W
Weight    7 kg
Dimensions   26x26x51 cm
    SEMI-AUTOMATIC PRECISION PENETROMETER
Power supply   230V ±10% 50Hz
Power   100W
Weight   9 kg
Dimensions   26x26x62 cm
